BigRep BVOH

BigRep BVOH Water-Soluble Support Filament

BigRep BVOH is a high-performance water-soluble support filament engineered to simplify post-processing for complex dual-extrusion 3D prints. Designed to create temporary support structures that dissolve completely in water, BVOH enables the production of intricate geometries, internal channels, and delicate overhangs that would be difficult or impossible to achieve with traditional breakaway supports.

Offering excellent adhesion to a variety of engineering materials, BigRep BVOH produces cleaner surface finishes while significantly reducing manual support removal. Once printing is complete, supports dissolve in cold or warm water, leaving behind high-quality parts with minimal post-processing effort.

Optimized for industrial FDM/FFF printing, BigRep BVOH is an ideal companion material for ASA, PLX, PRO HT, HI-TEMP, HI-TEMP CF, and TPU 98A when used in dual-extrusion printers.

Key Benefits

• Completely water soluble for effortless support removal
• Ideal for complex geometries and internal cavities
• Reduces post-processing time
• Nontoxic and odorless
• Excellent adhesion to supported materials
• Produces superior surface finishes compared to breakaway supports
• Compatible with a wide range of BigRep engineering materials
• Optimized for dual-extrusion printing

Typical Applications

• Complex functional prototypes
• Parts with internal channels or cavities
• Intricate engineering components
• Manufacturing fixtures and tooling
• Low-volume production parts
• Medical and research prototypes
• Architectural models
• Multi-material 3D printing projects

BigRep BVOH delivers reliable, water-soluble support for demanding additive manufacturing applications, allowing engineers and designers to create complex parts with exceptional surface quality while eliminating the challenges of manual support removal.

Specifications

Material: Butenediol Vinyl Alcohol Copolymer (BVOH)

Physical Properties

• Diameter: 2.85 mm
• Density: 1.14 g/cm³

Mechanical Properties

• Tensile Strength: 34 MPa
• Tensile Modulus: 2300 MPa
• Flexural Strength: 50 MPa
• Flexural Modulus: 2200 MPa

Thermal Properties

• Vicat Softening Temperature: 90°C
• Glass Transition Temperature (Tg): 68°C
• Melting Temperature: 175°C

Recommended Print Settings

• Nozzle Temperature: 190–210°C
• Build Plate Temperature: 50–70°C
• Cooling Fan: 0–100%

Additional Information

• Drying Recommendation: 60°C for 8–12 hours
• REACH Compliant: Yes
• RoHS Compliant: Yes
• FDA Compliant: No
