Formlabs BioMed Black Resin
RESIN · FORM 3 & 4 SERIES
BIOMED BLACK RESIN
Overview
BioMed Black Resin is a rigid, matte material for biocompatible applications requiring long-term skin (>30 days) or short-term mucosal membrane contact (<24 hours). Parts printed with BioMed Black Resin are compatible with common solvent disinfection and sterilization methods. BioMed Black Resin is manufactured in an FDA-registered, ISO 13485 certified facility and is also USP Class VI certified, which makes it suitable for pharmaceutical and drug delivery applications.


Why Choose BioMed Black Resin
BioMed Black Resin allows for the production of rigid, medical-grade parts where performance, aesthetics, and biocompatibility are critical. Manufactured under ISO 13485 quality standards in an FDA-registered facility, it is USP Class VI certified and tested for biocompatibility and sterilization compatibility. The dark, matte finish provides high contrast between substances or surfaces to aid in visual inspection and diagnostic workflows. Parts printed in BioMed Black Resin deliver excellent detail definition and smooth surface quality for complex designs. Recommended applications include end-use medical devices and components, biocompatible molds, jigs, fixtures, point-of-care applications, patient-contact parts, and consumer goods.
Technical Specifications
| Parameter | BioMed Black Resin |
|---|---|
| Ultimate Tensile Strength | 36 MPa |
| Tensile Modulus | 1500 MPa |
| Elongation | 14% |
| Flexural Strength | 57 MPa |
| Flexural Modulus | 1600 MPa |
| Shore Hardness | 77 D |
| Notched Izod | 25 J/m |
| Heat Deflection Temperature @ 0.45 MPa | 67.9 ºC |
| Compatible Printer | Form 4B, Form 4BL, Form 3B/3B+, Form 3BL, Form 2 |
