Formlabs BioMed White Resin
RESIN · FORM 3 & 4 SERIES
BIOMED WHITE RESIN
Overview
BioMed White Resin is a rigid material for biocompatible applications requiring long-term skin (>30 days) or short-term bone, tissue, dentin, and mucosal membrane contact (<24 hours). Parts printed with BioMed White Resin are compatible with common solvent disinfection and sterilization methods. BioMed White Resin is manufactured in an FDA-registered, ISO 13485-certified facility and is also USP Class VI certified, which makes it suitable for pharmaceutical and drug delivery applications.


Why Choose BioMed White Resin
BioMed White Resin is engineered for producing rigid, opaque parts for point-of-care and medical manufacturing applications where performance and biocompatibility are critical. Manufactured in an ISO 13485-certified facility, this medical-grade material delivers high visual contrast to aid in visual inspection and diagnostic workflows. It provides good detail definition to reliably print assemblies with complex designs and geometries. Recommended applications include end-use medical devices and device components, cutting and drilling guides, surgical tools and templates, anatomical models, patient-specific implant sizing models, and biocompatible molds, jigs, and fixtures.
Technical Specifications
| Parameter | BioMed White Resin |
|---|---|
| Ultimate Tensile Strength | 46 MPa |
| Tensile Modulus | 2000 MPa |
| Elongation | 10% |
| Flexural Strength | 74 MPa |
| Flexural Modulus | 2020 MPa |
| Shore Hardness | 80 D |
| Notched Izod | 15 J/m |
| Heat Deflection Temperature @ 0.45 MPa | 67 ºC |
| Compatible Printer | Form 4B, Form 4BL, Form 3B, Form 3BL, Form 2 |
