Standalone Reverse Engineering Software Compatible with Nearly Any CAD Software

Engineers who want access to 3D answers but don't have the time or willingness to learn complex traditional CAD tools will find Ansys SpaceClaim to be the ideal modeling option. It gives you the tools you need to speed up geometry preparation and get to simulation faster, all while reducing design team delays.

Request a Trial
Learn More

Ideal for Reverse Engineering

SpaceClaim offers tools that are ideal for reverse engineering. With SpaceClaim, STL files and solids can be easily altered to recreate perfect models for parts and fixtures. Users can even start with 2D models. Imperfect data from worn components or a dirty scan can be quickly corrected. Users Can:

  • Quickly create complex solids from scratch
  • Sketch curves along the facets of an STL file
  • Adjust a model's geometry
  • Easily create fixtures around mesh data
  • Convert 2D models or STL files into 3D models
  • Modify the geometry of worn parts
  • Clean up messy scans
  • And More!
  • Edit, repair and create any geometry

  • Prepare models for manufacturing steps and maximize machining time

  • Leverage scan data to reverse engineer new parts

  • De-feature CAD models
  • Extract fluid domains or simplify models for simulation
  • STL prep for 3D printing
  • Create, import, or repair sheet metal designs
